EKI-2701MPI
Hardened PoE injector, 1000Mbps, 90W
/EKI-2701MPI_Front-left-_S20191127111708.jpg)
- Supports operating temperatures from -40 ~ 75°C
- Provides slim size and DIN-rail with IP40 metal mechanism
- Power input 55~57 VDC, Inject power up to 90W
- IEEE802.3af/at/bt compliant
- Supports 10/100/1000Base-T (X) for PoE OUT and Data IN
With the technology of PoE (Power over Ethernet), both data and electrical power to Ethernet-enabled devices are using a standard CAT5 cable. EKI-2701MPI is a new generation injector which is IEEE802.3af/at/bt compliant. The high-power PoE standard boosts the power budget of each port up to 60W or even 90W to PD devices
